Single Axis Independent Solar Panel Track Mount Steel Power Tracking Frame System

Name: Single Axis Independent Solar Panel Track Mount Steel Power Tracking Frame System
Brand: Good Future Solar
Price: 1 USD

China Single Axis Independent Solar Panel Track Mount Steel Power Tracking Frame System wholesale

Brand Name : Good Future Solar

Model Number : MG/ZG/YG/JG.ETC SOLAR SYSTEM

Certification : CE/ISO/BV/SGS

Place of Origin : China

MOQ : Negotiate

Price : Negotiate

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000MW per Month

Delivery Time : 30 Working Days after design confirm

Packaging Details : Neutral packing

Product : Single Axis Independent Tracking Steel Power Tracking Frame System Solar Panel Track Mount

Driving System : Slew drive for tracker

Operation Temperature : -40℃ - +60℃

Night Position : Yes

Ground Coverage Ratio : ≥ 25%

String-Power : Yes

Damper : Included

Material : Galvanized Steel

Contact Now

Single Axis Independent Tracking Steel Power Tracking Frame System Solar Panel Track Mount

Working principle:
Ground mounting single axis solar tracking system components slew drive solar panel mounting brackets is controlled by the tracking controller, with simple structure, easy installation, flexible response, good reliability and strong fault identification ability. Compared with traditional fixed inclination installation, the generating capacity can be increased by 15%-20% (depending on local conditions).

Functions:
The solar tracker uses high-precision astronomy algorithm to calculate the angle of the sun,
combined with high-performance microcontroller (DSP core), making the system accurate
and reliable, not rainy days interference,using international first-line brand tilt sensor, real-time
closed-loop feedback tracking angle, automatic tracking, without human intervention.

Technical Parameters of One Axis Solar Tracker

Single Axis Independent Tracking Steel Power Tracking Frame System Solar Panel Track Mount
Tracking Range	士 60°
Driving System	Slew drive, 28VDC motor
Modules per Tracker	Max.90 modules per tracker
System Voltage	1000 V or 1500 V
Ground Coverage Ratio	≥ 25%
Power Consumption	0.2-0.5kWh/day
Power Supply Mode	Powered by PV strings, back-up lithium battery
Standard Design Wind Speed	18m/s
Module Supported	All commercially available modules
Operation Temperature	-40℃ - 60℃
Control Algorithm	Astronomical algorithms + Tilt sensor close loop
Tracking Accuracy	≤ 1°
String-Powered	Yes
Backtracking	Yes
Communication Options	LoRa wireless /RS 485 cable
Night Position	Yes

Good future solar has a professional management team, we have gains rich experiences on the solar power generation, and the designing, manufacturing, commissioning of the single axis tracking system. Our company always values customer’s needs as the highest priority, ready to provides technical support to our customers at any time, to solve their problems in the operation of PV power plant and solar tracking system. With the mission of developing clean energy and protecting the environment, we believe that through close cooperation with domestic and foreign customers, we will continue to innovate in technology and management, and create a bright future of clean energy!
