1P Single Row Solar Panels Tracker ISO Solar Tracking Device 1000V

Good Future Solar Technologies Co.,Ltd.
Contact Now

1P Single Row Solar Panels Tracker ISO Solar Tracking Device 1000V

Brand Name : Good Future Solar

Model Number : MG/ZG/YG/JG

Certification : BV/CE/ISO/SGS.etc

Place of Origin : China

MOQ : Negotiate

Price : Negotiate

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000MW per Month

Delivery Time : 30 Working Days after design confirm

Packaging Details : Neutral packing

Product : Unique patent solar tracking system sun solar tracker CE

System Voltage : 1000V or 1500V

Structure Material : Hot dipped galvanized & Pre-galvanized steel

Backing tracking : Provide

Tracking Range : ±60 degree

Desgin : Provide

Customized Order : Yes

Min. Order : 10KW

Contact Now

Unique patent solar tracking system sun solar tracker CE

Description

Popular solar trackers in the market has 3 types:passive, active and open loop trackers which is distinguished from drive and sensing or positioning system that they incorporate.
Passive trackers: The tracker has a gas sensing device and the tracker will move across the sky by using suns radiation to heat gases.
Active trackers: The tracker has an electric or hydraulic drives and some type of gearing or actuator. Good future 1P single row solar panels tracker belongs to this type of active trackers. It’s also the most popular type in the market right now.
Open loop trackers: Use no sensing but instead determines the position of the sun through pre-record data for a particular site.

1P Single Row Solar Panels Tracker ISO Solar Tracking Device 1000V

1P Single Row Solar Panels Tracker ISO Solar Tracking Device 1000V

Advantage:

1.Intelligent feedback

The controller adopts the inclination sensor of the international brand. Real-time closed-loop feedback tracks the tracking angle of the bracket, fully automatic tracking, without manual intervention.

2. Night reset function

At night, the components are restored to the initial maximum wind resistance state, and the errors caused by the day's operation are eliminated to ensure the accuracy of the entire tracking system;

3. Backtracking function

Reduces shading and maximizes power generation;

4.Information collection function

Real-time acquisition of component tilt Angle; Real-time acquisition of weather conditions, coordinate position, altitude, time and other information;

Technical Parameters
Product Unique patent solar tracking system sun solar tracker
Tracking Range 士 60°
Driving System Slew drive, 24VDC motor
Modules per Tracker Max.90 modules per tracker
System Voltage 1000 V or 1500 V
Structure Material Hot dipped galvanized/Pre-galvanized steel
Power Supply Powered by PV strings,back-up lithium battery
Module Supported All commercially available modules
Operation Temperature -30℃ - 60℃
Control Algorithm Astronomical algorithms + Tilt sensor close loop
Backtracking Yes
Night Position Yes
