best performance Single Axis Solar Tracker For solar panel Solar system

Description

Sigle axis tracking system is the latest generation ofproducts launched by Good Future Solar, canbe use as horizontal single-axis. Group moving of rotating stands through linkage ,it can be applied freely in the rugged slope ,as well as in many complex installation conditions such as hills ,river beaches ,deserts and Gobi Deserts .Power generatioin of single-axis tracking system is increased by 20%-25% compared with fixed support system.

Advantage:

1. Manual mode: The tracking angle can be manually adjusted, and the tracker panel reserves the indicator light indicating the running, stopping, and night return status of the power station.
2. Power-off memory: There is a backup battery inside the system, which can ensure that the system power-off data is not lost, and automatically enters the running state after power-on.
3. High power generation: The self-developed back tracking algorithm further improves power generation efficiency, ensures that the panel is always working in a non-shadow state, and increases the power generation of the panel and prolongs its service life.
4. High precision: The tracking system uses a high-precision astronomical algorithm to calculate the sun angle. Combined with a high-performance microcontroller (DSP core), the system calculates the position accurately and reliably, and can adapt to various operating environments without interference from rainy days.
5. High reliability: The system design is multi-channel communication and input and output isolated power supply. It can handle freely in the photovoltaic area with serious electromagnetic interference. Its excellent electromagnetic compatibility design ensures high reliability operation of the system.
6. Intelligent wind resistance: It is automatically leveled to the initial position at night. At the same time, the system has a wind load protection interface and supports an external wind speed sensor, which can control the system to enter the maximum wind resistance state of the machine at any time.
7. Intelligent feedback: use the international first-line brand inclination sensor, real-time closed-loop feedback bracket tracking angle, fully automatic tracking, no manual intervention.
8. Strong weather resistance: The system uses industrial grade chips and aerospace-grade clock sources to ensure safe and stable operation of the equipment in the range of -40 to +70 degrees without cumulative error.
9. Intelligent communication: The system is equipped with RS485-MODBUS standard communication interface, which can read real-time data of the device through software, and feedback the following information in real time:
(1) Sun angle, inclination angle, operating state, etc.
(2) Fault alarms such as actuators, inclination, limit, communication, etc.
(3) Remote start, stop, reset, manual, wind, snow, rain, etc.

About Good Future Solar

Good Future Solar is a professional solar power plant tracker supplier specializing in the design, development and production of solar tracking brackets. The company is a professional solar tracker global solution experts, we focus on low cost and low maintenance solution to create maximum value for customers. We are adhering to the concept of continuous in innovation in design and operation, committed to providing innovative technology and providing efficient and good quality solutions and safe products for global solar photovoltaic power plants.
