Ground Mounting 1P Tracker Hot Dipped Galvanized Slew Drive

Name: Ground Mounting 1P Tracker Hot Dipped Galvanized Slew Drive
Brand: Good Future Solar
Price: 1 USD

China Ground Mounting 1P Tracker Hot Dipped Galvanized Slew Drive wholesale

Brand Name : Good Future Solar

Model Number : MG/ZG/YG/JG

Certification : BV/CE/ISO/SGS

Place of Origin : China

MOQ : Negotiate

Price : Negotiate

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000MW per Month

Delivery Time : 30 Working Days after design confirm

Packaging Details : Neutral packing

Product : Factory direct supply solar tracking bracket pole bracket install ground mounting system

Driving System : Slew drive for solar tracker

Operation Temperature : -30℃-70℃

System Voltage : 1000V or 1500V

Structure Material : Hot dipped galvanized & Pre-galvanized steel

Backing tracking : Yes

Shipping Port : Qingdao/Tianjin/Shanghai

Tracking Range : ±60 degree

Desgin : Provide

Contact Now

Factory direct supply solar tracking bracket pole bracket install ground mounting system

Description

Ground mounting single axis solar tracking system components slew drive solar panel mounting brackets is controlled by the tracking controller, with simple structure, easy installation, flexible response, good reliability and strong fault identification ability. Compared with traditional fixed inclination installation, the generating capacity can be increased by 15%-20% (depending on local conditions).

Technical Parameters
Product	Factory direct supply solar tracking bracket pole bracket install ground mounting system
Tracking Range	士 60°
Driving System	Slew drive, 24VDC motor
Modules per Tracker	Max.90 modules per tracker
System Voltage	1000 V or 1500 V
Structure Material	Hot dipped galvanized/Pre-galvanized steel
Power Supply	Powered by PV strings,back-up lithium battery
Module Supported	All commercially available modules
Operation Temperature	-30℃ - 60℃
Control Algorithm	Astronomical algorithms + Tilt sensor close loop
Backtracking	Yes
Night Position	Yes

Ground Mounting 1P Tracker Hot Dipped Galvanized Slew Drive

Advantage:

1) It can respond to site features and changing weather conditions, and conditions to continuously optimizing the tracking algorithm of each individual row, to make boost solar power system production.
2) The most promising product technology trends in solar today. which help users get more power generated.
3) Simple structure ,easy in installation and debugger application.

About Good Future Solar

Good Future Solar is a professional solar power plant tracker supplier specializing in the design, development and production of solar tracking brackets. The company is a professional solar tracker global solution experts, we focus on low cost and low maintenance solution to create maximum value for customers. We are adhering to the concept of continuous in innovation in design and operation, committed to providing innovative technology and providing efficient and good quality solutions and safe products for global solar photovoltaic power plants.
