Ground mount solar tracking system solar powered tracker
Product Introduction
Horizontal single axis tracking system implements distributed actuation architecture, enabling each row to be independently controlled by its own motor with the tracking method “Astronomical algorithm + closed-loop control”. making the system accurate and reliable,real-time closed-loop feedback tracking angle, automatic tracking, without human intervention.
The system is controlled by the tracking controller, with simple structure, easy installation, flexible response, good reliability and strong fault identification ability. Compared with traditional fixed inclination installation, the generating capacity can be increased by 15%-20% (depending on local conditions).
Parameters of Ground mount solar tracking system solar powered tracker
| Technical Parameters |
| Tracking Range | 士 60° |
| Driving System | Slew drive, 24VDC motor |
| Modules per Tracker | Max.90 modules per tracker |
| System Voltage | 1000 V or 1500 V |
| Structure Material | Hot dipped galvanized/Pre-galvanized steel |
| Power Supply | Powered by photovoltaic strings,back-up lithium battery |
| Module Supported | All commercially available modules |
| Operation Temperature | -30℃ - 60℃ |
| Control Algorithm | Astronomical algorithms + Tilt sensor close loop |
| Backtracking | Yes |
| Night Position | Yes |
Choose Ground mount solar tracking system solar powered tracker will Provide Some Advantages:
1.Intelligent feedback
The controller adopts the inclination sensor of the international brand. Real-time closed-loop feedback tracks the tracking angle of the bracket, fully automatic tracking, without manual intervention.
2. Night reset function
At night, the components are restored to the initial maximum wind resistance state, and the errors caused by the day's operation are eliminated to ensure the accuracy of the entire tracking system;
3. Backtracking function
Reduces shading and maximizes power generation;
4.Information collection function
Real-time acquisition of component tilt Angle; Real-time acquisition of weather conditions, coordinate position, altitude, time and other information;
Company Introduction
Good Future Solar is a high-tech company in the clean energy industry, registered in China, address: Zhengzhou East New District, Henan Province, China. Our company is committed to provide the solar products of high reliability with competitive price to our domestic and foreign customers. Strive to build our brand in terms of leading technology, high quality and efficient service.
