Pv tracker single axis solar tracker manufacturers
Working principle:
Solar solar tracking systems can increase energy production by 25 percent compared to stationary systems. This means that more energy can be generated without increasing the size of the system, leading to smarter land use. While the benefits of energy generation are obvious, there are a few things to consider when deciding whether a single-axis tracking system is appropriate for your site's needs. Installation costs are usually higher because more work is usually required to prepare the site. The need for regular maintenance and repairs must also be considered, as the tracker uses mobile machinery. Single-axis solar tracking systems also tend to be heavier than fixed systems, making it better to use ground-mounted solar systems than rooftop ones. If deployed under the right conditions, solar trackers can quickly cover these initial costs by increasing energy production, adding significant value to the system.
Product Info:
The Good Future Solar 1P/2P uniaxial tracking system features a solar sensor that continuously checks the relative position of the sun and solar panels. The function can adjust the axis Angle, the solar panels from sunrise to sunset aligned into a vertical Angle of sunlight, compared with the fixed model, so that the solar panels receive solar energy for a long time, increase the solar power of the solar panel. After the test, the solar panel fixed installation power generation is more than 30-45% every day, the annual power generation is more than 25%.
Technical Parameters of Solar Sun Tracker
| Technical parameters |
| Tracking Range | 士 60° |
| Driving System | Slew drive, 28VDC motor |
| Modules per Tracker | Max.90 modules per tracker |
| System Voltage | 1000 V or 1500 V |
| Ground Coverage Ratio | ≥ 25% |
| Foundation Options | All foundation types |
| Standard Design Wind Speed | 18m/s |
| Module Supported | All commercially available modules |
| Operation Temperature | -40℃ - 70℃ |
| Control Algorithm | Astronomical algorithms + Tilt sensor close loop |
| Tracking Accuracy | ≤ 1° |
| String-Powered | Yes |
| Backtracking | Yes |
| Communication Options | LoRa wireless /RS 485 cable |
| Night Position | Yes |
Functions:
1. High integration, internal integration: GPS global positioning instrument, high-power motor driver chip, inclination sensor, tracking control system;
2. Compact size, fully sealed waterproof and dustproof, uv resistant, suitable for outdoor installation;
3. Easy to install, only need to access power supply, motor and limit switch 6 cables;
No debugging. The device can be tracked automatically by placing it on a solar stand without any debugging.
Advantages:
1. Compatible with larger modules
The Solar Tracker -1P is designed to reduce LCOE for larger modules. Compatible with 210 mm wafer size.
2. Innovative super tracker technology
The intelligent algorithm dynamically optimizes the tracking Angle according to real-time weather and actual terrain conditions to increase the received radiation and reduce shadow loss. Up to 8% yield gain.
3. Each tracker has more modules
Our two vertical configurations (2P) have up to 120 modules per tracker.
4. Faster installation design
Adopt solar panel fastener patent design, greatly improve the assembly efficiency.
|
|
Pv tracker single axis solar tracker manufacturers Images
|
