1 MW Customized Single Axis Solar Sun Tracker System
Working principle:
Solar sun tracking system can increase energy production by up to 25% compared with a fixed system. This means that more energy can be produced without needing to increase the size of the system, making for smarter use of land. While the energy generation benefits are clear, there are some things to consider when deciding if a single-axis tracking system is suited to your site’s needs. Installation costs are generally higher, as there is often more work to be done in prepping the site. The need for periodic upkeep and repairs must be considered too, as trackers utilize moving machinery. Single-axis solar sun tracking systems also tend to weigh more than fixed systems, so use in ground-mounted solar is preferred over roof-mounted solar. When deployed under the right conditions, solar trackers can add significant value to the system by boosting energy production that quickly makes up for these initial costs.
Product Info:
Good Future 1P/2P Single axis tracking system has a sun sensor which keep checking the sun and solar panel relative position. This function can adjust axis angle and arrange solar panel to be vertical sunshine angle from sunrise to sun-set, compare with fixed model, it make the solar panel receiving solar power with long time and increase the solar power of solar panel. According to testing, the power quantity is more than 30-45% comparing fixed installation of solar panel of each day, and >25% power generating rate for annual.
Technical Parameters of Customized Solar Sun Tracker Plant
| Technical parameters |
| Tracking Range | 士 60° |
| Driving System | Slew drive, 28VDC motor |
| Modules per Tracker | Max.90 modules per tracker |
| System Voltage | 1000 V or 1500 V |
| Ground Coverage Ratio | ≥ 25% |
| Foundation Options | All foundation types |
| Standard Design Wind Speed | 18m/s |
| Module Supported | All commercially available modules |
| Operation Temperature | -40℃ - 70℃ |
| Control Algorithm | Astronomical algorithms + Tilt sensor close loop |
| Tracking Accuracy | ≤ 1° |
| String-Powered | Yes |
| Backtracking | Yes |
| Communication Options | LoRa wireless /RS 485 cable |
| Night Position | Yes |
Functions:
1. Max terrain tolerance in N-S direction up to 15%.
2. Excellent compatibility with all the solar modules available on the market, framed, frameless and bi-facial.
3. Independent 2P module design, which reduces the quantity of posts and the installation cost significantly.
4. Innovative Super Tracker Technology
According to real-time weather and actual terrain conditions, Smart algorithm dynamically optimizes tracking angle, increases receiving radiation and reduces shading loss. UP TO 8% yield gain.
Advantages:
1.Weight-lifting structure with 5 supporting points, shaped table design combined with a four-link age structure,
driven by slewing drive.
2. Eliminates the water wave effect to prevent the impact of wind to the structure, eliminate the quiver and ensure the output efficiency of solar modules.
3. More stable distribution, lower steel structure cost, and avoid the deformation of structure.
4. Independent design, various landform adaptability, zero land leveling cost, make it suitable for solar agriculture,Solar-fishery projects and other application purpose, make it easy to install and maintain, and save maintenance cost.
Product Tags:
|
|
1MW Single Axis Tracking System Images
|
