Automatic Solar Tracker wind protection
Working principle:
In the aspect of solar photovoltaic application: keep the solar panel facing the sun at any time, so that the light of the sun's rays at any time perpendicular to the solar panel power device, the use of single axis automatic tracking system can significantly improve the power generation efficiency of solar photovoltaic modules.
Technical Parameters of Automatic Solar Tracker wind protection
| Technical parameters |
| Tracking Range | 士 60° |
| Driving System | Slew drive, 28VDC motor |
| Modules per Tracker | Max.90 modules per tracker |
| System Voltage | 1000 V or 1500 V |
| Ground Coverage Ratio | ≥ 25% |
| Foundation Options | All foundation types |
| Terrain Adaption | Up to 20% N-S slope |
| Structure Material | Hot dip galvanized steel |
| Power Consumption | 0.2-0.5kWh/day |
| Control Algorithm | Astronomical algorithms + Tilt sensor close loop |
| Tracking Accuracy | ≤ 1° |
| String-Powered | Yes |
| Backtracking | Yes |
| Communication Options | LoRa wireless /RS 485 cable |
| Night Position | Yes |
Product info:
1. High Cost Performance
Compared with solar mounting, the cost is increased by 8% to 10%. Obtain 15% to 18% higher power generation revenue than solar mounting.
2. Backtracking
The backtracking algorithm is implemented to drive the panel’s position during these periods of low solar height, in order to increase power generation.
3. Damper
Eliminate the resonance source at both ends of the flat uniaxial bracket. Enhanced wind resistance. The damper overcomes the vibration caused by irregular wind.
Advantages:
1. Lowest and optimized production cost
Through project design, the engineers help to offer simplest assembly and rapid installation results in costs and efficient construction schedules.
2. Simple link with tracker system Controller
Good Future Solar offers different types of tracker controller: with/without Lithium battery or self-power controller. All these just need very easy link and no more operations after installation.
3. Low maintenance and Outstanding longevity
The drivers will move the solar panel to slow position automatically at high wind speeds, this will protect the system from over-travel and increased solar system service life. The simple and robust design requires minimum maintenance.
About us:
Good Future Solar is a high-tech company in the clean energy industry, registered in China, address: Zhengzhou East New District, Henan Province, China. Our company is committed to provide the solar products of high reliability with competitive price to our domestic and foreign customers. Strive to build our brand in terms of leading technology, high quality and efficient service.
