Upgraded 2P Solar Tracker Low Ground Coverage Ratio
Working principle:
2P solar tracker can maximize your solar system's electricity production by directing your panels to follow the sun, which optimizes the angle at which your panels receive sunlight radiation. There are two types of solar tracking systems: single-axis and dual-axis.
Technical Parameters of Upgraded 2P Solar Tracker Low Ground Coverage Ratio
| Technical parameters |
| Tracking Range | 士 60° |
| Driving System | Slew drive, 28VDC motor |
| Modules per Tracker | Max.90 modules per tracker |
| System Voltage | 1000 V or 1500 V |
| Ground Coverage Ratio | ≥ 25% |
| Foundation Options | All foundation types |
| Terrain Adaption | Up to 20% N-S slope |
| Module Supported | All commercially available modules |
| Operation Temperature | -40℃ - 70℃ |
| Control Algorithm | Astronomical algorithms + Tilt sensor close loop |
| Tracking Accuracy | ≤ 1° |
| String-Powered | Yes |
| Backtracking | Yes |
| Communication Options | LoRa wireless /RS 485 cable |
| Night Position | Yes |
Product info:
A single-axis solar PV tracker moves your panels on one axis of movement, usually aligned with north and south. These setups allow your panels to track the sun from east to west.
Through project design, the engineers help to offer simplest assembly and rapid installation results in costs and efficient construction schedules.
Features:
1. Excellent compatibility with all the solar modules available on the market, framed, frameless and bi-facial.
2. Minimum annual power consumption
During the overcast sky, the Good future solar tracker will move the horizontal position to absorbed all the diffused light.
3. Adopt the form of self-power supply, without external power supply;
4. Independently developed MCU microcomputer control system;
5. Intelligent battery management system (BMS) and automatic alarm functions can ensure the system's long-term reliable operation.
6. Free obstacles among trackers in N-S direction, easy to maintain and clean.
7. Design configured with one single set of controller, which ensures point-to-point real-time monitoring, easy to detect fault points in time and reduce output loss.
About us:
Good Future Solar is a high-tech company in the clean energy industry, registered in China, address: Zhengzhou East New District, Henan Province, China. Our company is committed to provide the solar products of high reliability with competitive price to our domestic and foreign customers. We also provide a wide range of services, adapted to each project’s requirements. Our products have a reputation for reliability, cost competitiveness and advanced technology. Strive to build our brand in terms of leading technology, high quality and efficient service.
