Low Cost Horizontal Single Axis Solar Tracker with Low Ground Coverage Ratio
Company Description
Good Future Solar is a professional manufacture and trader specialized in research development and production of solar related products. We keeps Investing a lot of time and energy in product development, all of our products such as single axis solar tracking system and tacker system controller are comply with international quality standards, our clients give highly affirmation to our products and service throughout all the world.
Our Company
Good Future Solar provide high quality of solar system & solar tracker controller to clients around the world
Our Team
Our international trading team and professional technical supporting team will always work efficient and provide excellent service to customers from all over the world.
Our Values
Integrity, Accountability, Passion, Collaboration, Creating customer value, Employee growth.
Product Info:
Good Future 1P/2P Single axis tracking system is a device that orients a payload toward the sun. Since it can make PV panels track sunlight in east-west direction, it’s suitable for lower latitudes with high sun height angle. Compare with fixed sun panel tracking, its power generation efficiency is 20-30% higher and it can be installed at different ground level condition. Our single axis solar tracker includes mounting bracket for solar cell panel, horizontal shaft, rotation drive mechanism, wind speed detection device and tracking controller. Single axis solar tracker has one degree of freedom that acts as an axis of rotation. The axis of rotation of single axis trackers is typically aligned along a true North meridian. It is possible to align them in any cardinal direction with advanced tracking algorithm.
| Tracking Range | 士 60° |
| Driving System | Slew drive, 24VDC motor |
| Modules per Tracker | Max.90 modules per tracker |
| System Voltage | 1000 V or 1500 V |
| Structure Material | Hot dipped galvanized/Pre-galvanized steel |
| Power Supply | Powered by PV strings,back-up lithium battery |
| Module Supported | All commercially available modules |
| Operation Temperature | -30℃ - 60℃ |
| Control Algorithm | Astronomical algorithms + Tilt sensor close loop |
| Backtracking | Yes |
| Night Position | Yes |
| Work Time (h) | 24 |
| Output Frequency | 50/60Hz |
| Place of Origin | Henan, China |
| Packaging Details | Bulk Cargo of Wooden Containers and Containers |
| Bracket Material | Hot dip galvanized steel |
| Main Material | Q235B / Q355B |
Advantage:
Single axis solar tracker has a set of drives and controllers to realize automatic tracking for the entire array. The unique linkage structure and maintenance-free rotary bearing supports reliability, low failure rate and low maintenance cost.
1. The structure is simple, the parts are highly pre assembled, and the construction time is saved.
2. Independent driving single row design, no linkage rod, strong terrain adaptability and high plot ratio.
3. Reduce the force on the drive column by 50%.
4. Reduce spindle torsion angle by 60%.
5.Strong terrain adaptability, can be installed hillside. Hills and mountains
6.GPS automatic calibration, ensure accuracy
Main Features
1. Power generation efficiency increased by 35%~40%.
2. Simple structure ,easy in installation and debugger application.
3. Automatic control: The solar tracking system will provide protection automatically for different weather (rain, snow, high winds, etc. )
4. Improvement of power generation efficiency: Single axis solar tracker can increase power generation by 5% avoiding morning and nightfall shadows.
